Application:

Straight rulers, right triangle rulers, regular triangle rulers, protractor.

Different rulers print at the same time or multi prints at the same time.

(Different solution with different loading system, unloading system and fixtures)

    Description:

1. Auto loading rack for 4 kinds of rulers, other racks optional

2. 8 station indexer

3. Fixture with vacuum

4. PLC control, Touch screen display

5. Auto dust clean before printing

6. All servo motor driven: mesh frame up/down, printing, indexer, registration

7. Color registration tolerance: +0.005mm

8. Multi prints at the same time

9. LED drying after each color printing

10. Auto unloading belt with robot

11. Well safety protection with CE.

 Tech-data：

Printing colors: 2

Max.printing size: 200x300mm

Max.frame size: 250x500mm

Indexer station: 8 stations

Max.printing speed:4000-4800pcs/hr

Air pressure: 6~8bars

Power supply : 3phase, 380V, 50Hz

Power: 11.2KW

Dimension(LxWxH): 2000x2000x1800mm

Weight: 2300KG

       Samples:
