Description:
1. Conveyor speed and substrate rotation speed adjustable.
2. Half light (3KW) or full light (5.6KW) adjustable.
3. The distance between UV lamp and substrate adjustable.
Tech-data:
|
Tech-data |
UV200M |
|
Max. Curing Size |
Cylindrical：Φ200×280mm(H) Flat: 150(W)x300mm(L) |
|
Conveyor SpeedRange |
0-10m/min |
|
Speed Adjusting Mode |
electronic stepless mode |
|
Total Wattage |
6.4kw |
|
Lamp Wattage |
5.6kw |
|
Air Exhaust Fan Power Supply |
750W/1P/220V |
|
Conveyor Motor Power Supply |
60W/1P/220V |
|
Dimensions |
2200×700×1820mm |
|
Weight |
150kgs |
